Delivers up to 16.7 Amps continuous power from the 240V AC receptacle, up to 33.3 Amps continuous power from the four 120V AC outlets
AC welding with up to 1/8in. stick electrode
Up to 140 Amps of AC output for many applications
5,500 Watts surge (4,000 Watts continuous) AC generator power to run a grinder, work lights, pump, emergency power and more!
Kohler® 9 1/2 HP gasoline engine with overhead cam and cast iron cylinder liner for long life

Brand: Lincoln Electric
Manufacturer’s Warranty 3 year limited warranty
Weight 229.0 lbs
Product Type Welder/generator
Rated Watts (kW) 4,000
Surge Watts (kW) 5,500
Receptacles (qty.) 5
Circuit Breakers Yes
Welding Amperage Range 70–140A AC
Weldable Metals Stainless steel, steel, aluminum
Weld Thickness (in.) Unlimited w/multiple passes
Duty Cycle 125A AC/20V/30%, 100A AC/25V/60%
Clamp Cable Length (ft.) 20 w/optional K875 accessory kit
Engine Kohler
Engine Displacement (cc) 277
HP 9.5
Start Type Manual
Fuel Capacity (gal.) 1.9
Dimensions L x W x H (in.) 31 1/2 x 21 13/16 x 25 5/8
