Description

Working Height Up to 60′

Up to 30′ 10″ lateral outreach
31″ wide transport mode (will enter virtually any doorway)

15″ ground clearance with tracks
Fixed two-man aluminum basket (43″ x 27″ x 55″)
Proportional travel mode with wired remote control
Outrigger piston protective covers
LED display for error code detection
Honda GX390 gas engine
High-pressure air and water hose in the basket
120V Plug-in electric motor
12V Electrical socket in the basket
Fast proportional hydraulic controls

Jib movement 90°
Turret rotation +/- 356° (non-continuous)
Basket rotation +/- 90° (*optional)
Maximum slope to stabilize 17° (31%)
Height/Width track adjustment (*optional) 31″ – 46″
Maximum slope approach angle 28° (53%)
Gradeability (maximum climbing angle) 37° (75%)
Lightweight 5,269 lbs
Travel speed 1.5 MPH
